AutoCAD Commands & Shortcut Keys

COMMAND

SHORT KEY

ARC (PART OF CIRCLE)

A

ARRAY

AR

BLOCK

B

BOUNDARY

BO

BREAK

BR

CHAMFER

CHAMFER

CHANGE UCS

F5

CIRCLE

C

CONSTRUCTION LINE (HELPING LINE)

XL

COPY

CO

DIMENSION

DIM

DIMENSION STYLE

D

DIVIDE: DIVIDE A LINE / CIRCLE IN EQUAL PARTS

DIV

DONUT: CONCENTRIC CENTER CIRCLES (SAME CENTER OF TWO CIRCLES)

DO

ELLIPSE

EL

ERASE

E

EXPLODE

X

EXTEND

EX

EXTRUDE

EXT

FILLET

F

GRID

F7

HATCH / GRADIENT

H

INSERT BLOCK

I

JOIN

J

LENGTHEN

LEN

LIMITS

LIMITS

LINE

L

LINE TYPE SCALE FACTOR

LTS

MATCH PROPERTIES

MA

MEASURE

ME

MIRROR

MI

MOVE

M

MULTI LINE TEXT

MT

MULTILINE (DRAW TWO OR MORE LINES)

ML

OBJECT TRACK

F11

OFSET

O

OPTIONS

OP

ORTHO

F8

OSNAP (OBJECT SNAP)

F3

PAGE SETUP

MVSETUP

PEDIT

PE

POINT

PO

POLAR

F10

POLY LINE

PL

POLYGON

POL

PROPERTIES

CTL+1

QUICK DIMENSION

QDIM

RECTANGLE

REC

REGION

REG

RENDING

RR

REVISION CLOUD


REVOLVE

REV

REVOLVE SURFACE

REVSURF

ROTATE

RO

SCALE

SC

SNAP

F9

SPLINE (IRREGULAR LINE AND IRREGULAR CURVE)

SPL

STRETCH

S

SUBTRACT

SU

TABLE

TABLE

TEXT

T

TRIM

TR

UNION

UNI

UNITS

UN

ZOOM (TO DISPLAY ALL WORKING AREA)

Z OR BUBBLE CLICK ON MOUSE WHEEL
